SKADIS - paint rack for Vallejo and Citadel

Hey all,

I redesigned and updated the original… not by much. I divided the project into two folders: 17ml Vallejo and 12ml Citadel folders. Each folder has all the files you need for the specific paint rack that will fit on the Skadis wall system.

With this update the 17ml bottle racks have changed a smidge. I have increased the radius of the bottle openings by 0.5mm as I found it very snug with some bottles. The increase of radius should give it a bit of wiggle room for easy insert/removal.

Both paint racks are designed to be easily printed on P1P, P1S and X1C.

----- 17ml Vallejo, AK, Army Painter -----

Print the following quantities for single rack. This will hold 45 paints:

- sides x2;

- 8 paint shelf x3;

- 7 paint shelf x3;

- paint rack bottom x1; and

- paint rack top x1

Print the following quantities for double rack. This will hold 90 paints:

- sides x4;

- 8 paint shelf x6;

- 7 paint shelf x6;

- paint rack bottom x1; and

- paint rack top x1

----- 12ml Citadel paint pods -----

Print the following quantities for single rack. This will hold 35 paints:

- sides x2;

- 4 x paint shelf;

- paint rack bottom x1; and

- paint rack top x1

Print the following quantities for single rack. This will hold 70 paints:

- sides x4;

- 8 x paint shelf;

- paint rack bottom x1; and

- paint rack top x1

My rack was printed mainly with BL jade white Basic PLA and some Creality HS PLA. I noticed that the parts that were printed with the BL Basic PLA had better fit than other PLAs.
