Ark Nova and Marine Worlds Deluxe Insert

for Ark Nova (2021) Layer by Layer

Inserts Free

View on MakerWorld 430 1,769 Added Feb 18, 24 | Updated Aug 6, 26 Support SH Designs by Liking and Boosting their model.

Plan Your Print

✓ Covers Ark Nova: Marine Worlds Expansions this print stores alongside the base game

✓ Fits sleeved cards

About 1,184 g of filament From the designer's print profile

Print Profile (5) ALL PARTS - .20mm 25h 26m 1,184 g PLA

ALL PARTS - .20mm

10 plates 25h 26m 1,184 g PLA

P1S, P1P, X1, X1 Carbon, X1E, A1, H2D, H2D Pro, H2S, P2S, H2C, X2D, A2L

0.20mm layer, 2 walls, 15% infill. No supports needed.

Plate Details (10)

0.4 mm nozzle, all plates

Plate 1 · Continent, University and Setup Trays

2h 36m 113 g PLA · 113 g

Plate 2 · Solo and Spare Tray

1h 36m 73 g PLA · 73 g

Plate 3 · Kiosk and Pavillion Tray

1h 22m 61 g PLA · 61 g

Plate 4 · Special Enlcosure= Print 2x

1h 52m 76 g PLA · 76 g

Plate 5 · Unique Building Trays 1

1h 56m 76 g PLA · 76 g

Plate 6 · Unique Building Trays and Holder

2h 18m 105 g PLA · 105 g

Plate 7 · Player Trays

3h 23m 178 g PLA · 178 g

Plate 8 · Money Trays

3h 20m 176 g PLA · 176 g

Plate 9 · Basic Enclosure Trays

3h 20m 160 g PLA · 160 g

Plate 10 · Card Trays

3h 44m 166 g PLA · 166 g

Split trays for A1 mini

2 plates 4h 4m 175 g PLA

A1 mini, P1S, P1P, X1, X1 Carbon, X1E, A1, H2D, H2D Pro, H2S, P2S, H2C, X2D, A2L

I split the trays for the standard enclosures as well as the Money/X/2X tray to fit on the A1 mini.

Plate Details (2)

0.4 mm nozzle, all plates

Plate 1 · Standard Enclosure

2h 7m 83 g PLA · 83 g

Plate 2 · Money,2X,X

1h 58m 92 g PLA · 92 g

Alternate Spec Enc Tray 2

1 plate 1h 1m 38 g PLA

P1S, P1P, X1, X1 Carbon, X1E, A1, H2D, H2D Pro, H2S, P2S, H2C, X2D, A2L

If you have a 1x4 enclusure piece that doesn't fit in the tray, this one has a larger spot for it. Thank you to @sfremund78 for showing us the descrepancy.

Plate Details (1)

0.4 mm nozzle, all plates

Plate 1

1h 1m 38 g PLA · 38 g

0.2mm layer, 2 walls, 15% infill

1 plate 1h 1m 38 g PLA

P1S, P1P, X1, X1 Carbon, X1E, A1, A1 mini, H2D, H2D Pro, H2S, P2S, H2C, X2D, A2L

Adjusted slots for the three pieces that don't quite fit, and also made the hole for the single tile slot smaller so that it doesn't fall through it easily. Not perfect as I could not make the hole for the dinosaur slot bigger in the mesh due to my lack of knowledge. UPDATED 19/12 non-manifold edges fixed.

Plate Details (1)

0.4 mm nozzle, all plates

Plate 1

1h 1m 38 g PLA · 38 g

A1 0.2mm layer, 2 walls, 15% infill

2 plates 3h 14m 114 g PLA

A1, P1S, P1P, X1 Carbon, X1E, X1, H2D, H2D Pro, H2S, P2S, H2C, X2D, A2L

Ich habe lediglich die Anordnung der usprünglichen “Special Tiles” genommen und auf die richtige Größe skaliert damit sie in die vorgefertigte Box passen. Ich hatte das Ursprüngliche Ordnungssystem gedruckt und bin jetzt durch meinen neuen A1 und das AMS auf die Pavillons und Kioske gestoßen. Damit die auch in die Packung passen muss man lediglich die Box sowie die dafür vorgesehenen Tableus für die Sonderbauwerke sowie die Spezialgehege drucken und schon passt alles rein. Da ich allerdings auch Probleme mit den originalen Spezialgehegen hatte (sie haben einfach nicht gepasst) hab ich mich dazu entschieden sie kurzerhand selbst in Fusion zu designen. Ich hoffe ich kann damit einigen helfen die das gleiche Problem wie ich hatten =)

Plate Details (2)

0.4 mm nozzle, all plates

Plate 1 · Arche Nova Special Insert 1 und 2

2h 5m 76 g PLA · 76 g

Plate 2 · Arche Nova Special Insert 3

1h 8m 38 g PLA · 38 g

As sliced by the designer. Your printer, filament, and settings may change these numbers.

Designer's Description

Deluxe Insert for Ark Nova and Marine Worlds Expantion. I started with the Insert designed by Suzan & Eerko Vissering on Thingiverse as reference above, but rebuilt it from scratch and redesigned everything to fit my own preferences. The major differences are the additon of a tray for 3D printed kiosks and pavillions, redesign of the unique and special enclosure trays to fit in a larger master tray, and differences in the setup tray to include space for a 3D printed coffee mug and an extra tray for spare parts.

Printed in Bambu Matte PLA Marine Blue

To complete the entires sytem you will need to print:

4 player part trays

4 card trays (fits sleeved cards)

2 basic enclosure trays (2up on the plate)

2 money trays (2up on plate)

4 special enclosure trays (2 up on plate)

1 each of the 3 unique enclosure trays

1 “Tray of trays” to fit the unique and special enclosure trays

1 Tray for 3D printed Kiosks and Pavillions

1 univeristy and continent tray

1 setup tray

1 solo tray

1 spare parts tray

3D Kiosks and Pavillion can be found here: https://www.thingiverse.com/thing:5523872

3D Coffee Mug can be found here: https://www.thingiverse.com/thing:5255675

Metal Coins can be purchased here
Boost Me Thank you for enjoying this model. Please send me a boost to help launch new fun projects! Thank you!!

Enjoy the model and let me know if you have any suggestions for improvement. This is by far our favorite board game and are always looking for ways to make it even better.
