cloud box · magnetically stackable · modular

for Tabletop Accessories Layer by Layer

h3li0

Storage & Containers Free

View on MakerWorld 807 785 Added Apr 25, 24 | Updated Sep 2, 26 Support h3li0 by Liking and Boosting their model.

Plan Your Print

About 301 g of filament From the designer's print profile

Print Profile (3) stackable with 6x3mm magnets 7h 2m 301 g PLA

stackable with 6x3mm magnets

4 plates 7h 2m 301 g PLA

X1 Carbon, P1S, P1P, X1, X1E, A1, H2D, H2D Pro, H2S, P2S, H2C, X2D, A2L

• 0.20mm layer height • 15% cubic infill • no supports or brims needed

Plate Details (4)

0.4 mm nozzle, all plates

Plate 1 · boxes

3h 27m 168 g PLA · 168 g

Plate 2 · lid

58m 37 g PLA · 37 g

Plate 3 · feet · optional

29m 15 g PLA · 15 g

Plate 4 · inserts · optional

2h 7m 81 g PLA · 81 g

cbox by plates - 0.2mm layer, 2 walls, 15% infill - A1 mini

8 plates 8h 24m 301 g PLA

A1 mini, P1S, P1P, X1, X1 Carbon, X1E, A1, H2D, H2D Pro, H2S, P2S, H2C, X2D, A2L

Separated by plates - 0.2mm layer, 2 walls, 15% infill - Optimized for the A1 mini

Plate Details (8)

0.4 mm nozzle, all plates

Plate 1 · box1

1h 25m 56 g PLA · 56 g

Plate 2 · box2

1h 25m 56 g PLA · 56 g

Plate 3 · box3

1h 25m 56 g PLA · 56 g

Plate 4 · inserts · optional

55m 28 g PLA · 28 g

Plate 5 · feet · optional

30m 15 g PLA · 15 g

Plate 6 · lid

1h 1m 37 g PLA · 37 g

Plate 7 · inserts · optional

51m 26 g PLA · 26 g

Plate 8 · inserts · optional

52m 27 g PLA · 27 g

Large Version - 1.5 scale

3 plates 10h 10m 441 g PLA

A1, P1P, X1, X1 Carbon, P1S, X1E, H2D, P2S, H2C, H2D Pro, H2S, X2D, A2L

• 0.2mm layer height • 2 walls • 6% infill density • No supports needed Scaled up the boxes, lid, feet, and one of the optional inserts by 1.5x. I also adjusted the size of the magnet holes to be able to fit 10mm x 3mm magnets, as the body is larger and would require larger magnets. The inside of the box should measure 88.5mm(w) x 216mm(l) x 36mm(h), perfect for makeup or pens/pencils/stationaries. Print profile has the models with 6% infill density as it cuts the time and filament by a good chunk, and I didn't require the box to be too tough. However, feel free to adjust it to your liking.

Plate Details (3)

0.4 mm nozzle, all plates

Plate 1 · 1.5scale Cloud Box (x2)

5h 58m 233 g PLA · 233 g

Plate 2 · 1.5scale Insert & Lid

3h 25m 176 g PLA · 176 g

Plate 3 · 1.5scale Feet

47m 32 g PLA · 32 g

As sliced by the designer. Your printer, filament, and settings may change these numbers.

Designer's Description

cloud box

modular and stackable through magnets

check out companion model cloud organiser · modular

this is a modular design that consists of the boxes themselves, lid, and as options you have feet and inserts. the stacking between the boxes, lid and feet is achieved through the use of 6x3mm magnets. These are affordable and readily available in many stores (i purchased mine from amazon in a pack of 100), and enable the stacking of the components, resulting in a satisfying "thock" sound and smooth action.

You'll need 16 6x3mm magnets to achieve the same result as shown in the pictures and included in the print profile, as well as some drops of super glue to ensure they really stay in their position and don't get pulled away from the slot.

please make sure that you are very mindful of the polarities of the magnet when assembling and gluing in their spots as you want to make sure that each section atracts and not repels the one that will sit above/below

print profile consists of 4 plates as seen below . the feet and inserts are optional, but for me the inserts really make the finishing touch and increase the flexibility. there is 3 different designs of inserts, and they all have 1mm thickness walls, and are design with very small tolerances to ensure a perfect tight fit , so make sure that you have your machine calibrated and filament dry so that you don't run into any tolerance issues

photos shows printed in matte white pla, matte black pla and bronze silk pla

0.20mm layer height
15% cubic infill
no supports or brims needed

commercial licence membership available on my

note: all photos uploaded are of the actual printed model, taken inside a lightbox or in home studio

stackable magnetic modular cloud segment decor desk desktop magnet office
